The series has compact design, small host width and good passability. Use variable amplitude working arm. Ensures a strong load carrying capacity in a smaller width.
The width of the main machine is the smallest in all the sliding machine products. To meet special operational requirements.
The product uses imported European and American hydraulic parts. Sensitive control, rapid response, is the best choice for small space operations.
We can provide customized services according to your needs.
| Performance Parameters | Working Parameters | ||
| Rated loading capacity : | 300kg | Bucket pin Height : | 2200mm |
| Maximum driving speed: | 8 (high speed) | Overall length without bucket: | 2180mm |
| Minimum travel speed: | 4(low speed) | overall length with bucket: | 2680mm |
| Tire track model: | 18*8.5-8 | Dumping angle at maximum height: | 38° |
| Engine brand: | Briggs&Stratton | Dumping height: | 1770mm |
| Rated power : | 13.5HP | Dumping reach: | 200mm |
| Fuel tank capacity : | 20L | Wheelbase: | 950mm |
| Machine net weight: | 800kg | Ground clearance: | 140mm |
| Working weight: | 1200KG | Big arm width: | 340mm |
| Bucket capacity: | 0.15 (m3) | Width: | 960mm |
| Overall operating height: | 2750mm | Bucket width : | 1000mm |
Choose reliable logistics
1. Co-operation with excellent carriers: By cooperating with world-renowned logistics partners, we provide high-quality logistics services with full traceability to ensure timely and accurate delivery around the world.
2. Full tracking: We are committed to safe and efficient packaging methods to ensure the integrity of the equipment during long-distance transportation.
Arrival and acceptance guide
1. Unpacking guide: Detailed unpacking and inspection tips are attached with the shipment, instructing customers how to open the package safely and check the condition of the excavator.
2. After-sales service: Provide 24-hour online technical assistance to ensure that subsequent problems can be solved in a timely manner.
