Beautiful appearance, compact structure, standard forklift operating table, high safety factor, five 120 maintenance-free batteries, equipped with intelligent 60V DC controller, brake power off, undervoltage protection, overcurrent protection, overload protection, speed limit protection, underspeed protection, front and rear axle differential protection. The above protection functions make the motor more energy-saving and durable, and can work continuously for six hours.
Electric loaders are a type of engineering machinery driven by electricity, mainly used for earthwork, construction waste handling, ore excavation, material loading and unloading, etc. Compared with traditional diesel loaders, electric loaders are powered by batteries or directly connected to the power supply, which not only has lower emissions and reduces environmental pollution, but also reduces operating costs and maintenance costs.
Electric loaders are gradually emerging in the increasingly stringent environmental regulations and market demands due to their advantages such as environmental protection, low noise, and low operating costs. It is suitable for use in urban construction, mining operations, and environmental protection. In the future, technological advances in green environmental protection and intelligence will further promote its application and development.
| Performance Parameters | Working Parameters | ||
| Rated load capacity | 500kg | Overall dimension (L*W*H) | 2700 * 1160 * 2175 mm |
| Total weight | 1260 kg | Max. Lifting height | 2520mm |
| Loadingbucket capacity | 0.3m3 | Max. Dump height | 1738 mm |
| Travel speed | 15km/h | Max. Dump distance | 700 mm |
| 120 Battery x5 | 60V（DC） | Turning radius | 3100 mm |
| Boom lifting time | 5—7s | Min. Ground clearance | 200 mm |
Choose reliable logistics
1. Co-operation with excellent carriers: By cooperating with world-renowned logistics partners, we provide high-quality logistics services with full traceability to ensure timely and accurate delivery around the world.
2. Full tracking: We are committed to safe and efficient packaging methods to ensure the integrity of the equipment during long-distance transportation.
Arrival and acceptance guide
1. Unpacking guide: Detailed unpacking and inspection tips are attached with the shipment, instructing customers how to open the package safely and check the condition of the excavator.
2. After-sales service: Provide 24-hour online technical assistance to ensure that subsequent problems can be solved in a timely manner.
